HF-P 118 136 TL-D III 220-240V 50 60 Hz Online Hot Sale

General information

Remarks		UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG
Application code		III
Type version		IDC
Lamp type		TL-D

Number of lamps		1 piece unit
Number of products on MCB (16 A type B) (nom.)		28
Automatic restart		Yes

Operating and electrical

Input Voltage		220 to 240 V
Input frequency		50 to 60 Hz
Operating frequency (nom.)		45 kHz
Ignition method		Programmed Start
Crest factor (max.)		1.7
Power factor 100% load (nom.)		0.99
Ignition time (max.)		0.9 s
Mains voltage performance (AC)		-8%-+6%

Mains voltage safety (AC)		-10%-+10%
Earth leakage current (nom.)		0.5 mA
Inrush current width		0.25 ms
Constant wattage deviation		-2% +2%
Ballast factor (nom.)		1
Power losses (nom.)		2.5-4.1 W
Inrush current peak (max.)		18 A
Efficiency at full load [%]		91.5 %
