DNA 2 High Output DALI Addressable Conversion Range Supply

3 hour High Output DALI self-test emergency lighting conversion kit, designed to suit an extremely wide range of LED types and circuits. The DNA 2  automatically adjust the output LED current to provide the best match between the battery and the load, providing maximum illumination whilst ensuring full battery duration. The DNA 2 will operate LED loads between 6-55V forward and the DNA 2 80 will operate LED loads between 6 and 80V forward.

Where space inside the luminaire is limited and the 2-cell battery is too high, the DNA 2S can be supplied which has a slimmer batteries.

This product is fully DALI compliant and in keeping with the DALI Standard, if the module is commissioned without a DALI control system present, the unit will revert to standalone self-test, indicating its faults via the charge LED.

Order Codes

Order Code		Description
DNA 2-K		Module, two cell battery and charge LED indicator for LED loads from 6-55Vf
DNA 2 TP40		Above two cell kit housed in a two part enclosure for 40mm apertures
DNA 2 80-K		Module, two cell battery and charge LED indicator for LED loads from 6-80Vf
DNA 2 80 TP40		Above two cell kit housed in a two part enclosure for 40mm apertures
DNA 2 IP65		6-55V Module and two cell battery housed in an IP rated enclosure with IP rated LED
DNA 2 80 IP65		6.80V Module and Two cell battery housed in an IP rated enclosure with IP rated LED
DNA 2S-K		Module, six cell battery and charge LED indicator for LED loads from 6-55Vf
DNA 2S 80-K		Module, six cell battery and charge LED indicator for LED loads from 6-80Vf

Order Codes - See Description	DNA/2-K, DNA/2/TP40, DNA/2/80-K, DNA/2/80/TP40, DNA/2/IP65, DNA/2/80/IP65, DNA/2S-K, DNA/2s/80-K
