PWM-90-48 – Mean Well LED Driver PWM-90-48 90W 48V For Discount
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant voltage PWM form output0~10Vdc or PWM input signal dimming functionProtections: Short circuit Overload Over voltage Over temperatureOther features:Universal AC input Full range (up to 305VAC)Dimming range: 0~100%High efficiency up to 90.5%Class II power unit, no FGSuitable for dry damp wet locationsNo load power consumption <0.5W5 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
90
Output Voltage
48V
Dimmable (Type)
AC phase-cut
Dimensions
171x 63x 37.5
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (?60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge L-N: 2KV), criteria A
Input Voltage
90~305VAC 127~431VDC
Safety Standards
UL8750, CSA C22.2 No. 250.13-12, EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved; Design refer to EN60335-1
Output Voltage Options
Single
Working Temperature
-40-+70°C
PDF Datasheet
PWM-90-spec.pdf
