PLN-30-27 – Mean Well LED Driver PLN-30-27 30W 27V Online Hot Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Built-in constant current limiting circuit (C.V. + C.C. mode)Fully isolated plastic case with IP64 levelProtections: Short circuit Overload Over voltage Over temperatureOther features: Universal AC input Full RangeBuilt-in active PFC function, PF>0.9 for 75% of load or higherClass 2 power unit Pass LPSIsolation class II, no F.G.User adjustable output voltage and current protection levelCooling by free air convection2 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
30
Output Voltage
27V
Dimmable (Type)
No
DC Output Adjustment
95%~108% rated output voltage adjustable by internal potentiometer
Dimensions
145 x 47 x 30
EMC Standards
EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage
90~295VAC
Safety Standards
UL8750, UL1310, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13
Output Voltage Options
Single
Working Temperature
-20~+70°C
PDF Datasheet
PLN-30-SPEC.PDF
