PLN-20-24 – Mean Well LED Driver PLN-20-24 20W 24V Online
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Built-in constant current limiting circuit (C.V. + C.C. mode)Fully isolated plastic case with IP64 levelProtections: Short circuit Overload Over voltage Over temperatureOther features: Universal AC input Full RangeBuilt-in active PFC function, PF>0.9 for 75% of load or higherClass 2 power unit Pass LPSIsolation class II, no F.G.Current protection levelCooling by free air convection2 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
20
Output Voltage
24V
Dimmable (Type)
No
DC Output Adjustment
N A
Dimensions
148.5 x 38.5 x 28
EMC Standards
EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage
90~277VAC
Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13
Output Voltage Options
Single
Working Temperature
-30~+70°C
PDF Datasheet
PLN-20-SPEC.PDF
