PLD-40-1750B – Mean Well LED Driver PLD-40-1750B 40W 1750mA For Cheap

180~295VAC inputBuilt-in active PFC functionProtections: Short circuit Over temperatureOther features:Constant current designFully isolated plastic caseIP30 designClass 2 power unit Pass LPSIsolation class II, no F.G.100% full burn-in testCooling by free air convection3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
40

Output Current
1750mA

Dimmable (Type)
No

Dimensions
128x 60x 31.5

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A

Input Voltage
180~295VAC

Safety Standards
UL8750, ENEC EN61347-1, EN61347-2-13 independent, IP30 approved

Output Voltage Options
Single

Working Temperature
-30~+60°C

PDF Datasheet
PLD-40-spec_8.pdf
