PLD-25-350 – Mean Well LED Driver PLD-25-350 20W 350mA Online

Built-in active PFC functionConstant current designProtections: Short circuit Over temperatureOther features:Fully isolated plastic caseConstant current designClass 2 power unit Pass LPSIsolation class II, no F.G.Cooling by free air convection3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
20

Output Current
350mA

Dimmable (Type)
No

EMC Standards
EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547

Input Voltage
90~295VAC 127~417VDC

Safety Standards
UL8750, ENEC EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+50°C

PDF Datasheet
PLD-25-spec_3.pdf
