PLD-16-1050B – Mean Well LED Driver PLD-16-1050B 16W 1050B Supply

Built-in active PFC functionConstant current designProtections: Short circuit Over temperatureOther features:Fully isolated plastic caseConstant current designClass 2 power unit Pass LPSIsolation class II, no F.G.Cooling by free air convection3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
16

Output Current
1050mA

Dimmable (Type)
No

EMC Standards
EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547

Input Voltage
180~295VAC

Safety Standards
UL8750, ENEC EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+50°C (Refer to Derating Curve )

PDF Datasheet
pld-16-spec.pdf
