PLC-30-24 – Mean Well LED Driver PLC-30-24 30W 24V Online Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Built-in constant current limiting circuit (C.V. + C.C. mode)Protections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input full rangeFully isolated plastic case with screw terminal style of I OAdjustable output voltage and current levelBuilt-in active PFC function, PF>0.9 for 75% of load or higherHigh efficiency up to 90%Class 2 power unit Pass LPSIsolation class II, no F.G.Cooling by free air convection100% full load burn-in test2 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
30
Output Voltage
24V
Dimmable (Type)
No
DC Output Adjustment
16.8~24V
Dimensions
160 x 47 x 30
EMC Standards
EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage
90~264VAC; 127~370VDC
Safety Standards
UL1310, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved
Output Voltage Options
Single
Working Temperature
-30 ~ +60°C (Refer to Derating Curve )
PDF Datasheet
PLC-30-spec_4.pdf
