NPF-90-42 – Mean Well LED Driver NPF-90-42 Series 2.15A 90.3W Discount

Fully encapsulated with IP67 levelProtections: Short circuit Over Current Over voltage Over temperatureOther features:Universal AC input (up to 305VAC) Full RangeHigh efficiency up to 91%Cooling by free air convectionBuilt-in active PFC functionFully isolated plastic caseClass II power unit, no FGSuitable for dry, damp, wet locationNo load power consumption <0.15W5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
90

Output Voltage
42V

Dimmable (Type)
No

DC Output Adjustment
25.2-42V

Dimensions
171x 63x 37.5

EMC Standards
Compliance to EN55015, EN55022 (CISPR22) Class B, EN61000-3-2 Class C (>60% load) ; EN61000-3-3, Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, EN55024, light industry level(surge L-N : 2KV), criteria A.

Input Voltage
90-305VAC

Safety Standards
UL8750, CSA C22.2 No. 250. 13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved; Design refer to EN60335-1

Output Voltage Options
Single

Working Temperature
-40-+80°C

PDF Datasheet
NPF-90-spec.pdf
