LPV-60-24 – Mean Well 60W 24V LED Driver LPV-60-24 Fashion
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant Voltage Fully encapsulated with IP67 level
Protections: Short circuit Overload Over voltage
Other features: Universal AC input Full Range Class 2 power unit Isolation class II, no F.G. Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS 100% full load burn-in test Low cost,
High reliability 2 years warranty
More Information:
Manufacturer: Mean Well
Output Wattage (W) 60
Output Voltage 24V
Dimmable (Type) No
DC Output Adjustment N A
Dimensions 162.5 x 42.5 x 32
EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage 90~264VAC
Safety Standards UL1310, UL879 approved;
Design refer to TUV EN60950-1, EN61347-2-13
Output Voltage Options Single
Working Temperature -30°C~+70°C
