LPV-35-36 – Mean Well LED Driver LPV-35-36 35W 36V For Discount

Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit Overload Over voltage
Other features:

Universal AC input Full Range
Class 2 power unit
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
35

Output Voltage
36V

Dimmable (Type)
No

DC Output Adjustment
N A

Dimensions
148 x 40 x 30

EMC Standards
EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11

Input Voltage
90~264VAC

Safety Standards
UL1310 approved; Design refer to TUV EN60950-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-30°C~+70°C

PDF Datasheet
LPV-35-SPEC.PDF
