LPV-20-15 – Mean Well LED Driver LPV-20-15 20W 15V Fashion
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit Overload Over voltage
Other features:
Universal AC input Full Range
Class 2 power unit
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
20
Output Voltage
15V
Dimmable (Type)
No
DC Output Adjustment
N A
Dimensions
118 x 35 x 26
EMC Standards
EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage
90~264VAC
Safety Standards
UL1310, UL879 approved; Design refer to TUV EN60950-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-30°C~+70°C
PDF Datasheet
LPV-20-SPEC.PDF
