HF-R 236 TL-D EII 220-240V 50 60Hz 1-10V Dimmable 2 x 36W Fashion

General Information

Remarks		UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG
Application code		EII
Type version		mk2
Lamp type		TL-D

Number of lamps		2 piece unit
Number of products on MCB (16 A type B) (nom.)		12
Automatic restart		Yes

Operating and Electrical

Input Voltage		220 to 240 V
Input frequency		50 to 60 Hz
Operating frequency (max.)		89 kHz
Operating frequency (min.)		45 kHz
Ignition method		Programmed Start
Crest factor (max.)		1.7
Power factor 100% load (nom.)		0.98
Ignition time (max.)		0.2 s

Mains voltage performance (AC)		-8%-+6%
Mains voltage safety (AC)		-10%-+10%
Earth leakage current (max.)		0.5 mA
Inrush current width		0.40 ms
Power losses (nom.)		7.3 W
Inrush current peak (max.)		45 A
Efficiency at full load [%]		88.69 %
