ELG-200-36DA – Mean Well LED Driver ELG-200-36DA 96W 36V – DALI Dimming Supply

Constant current mode output
Typical lifetime>50000 hours
Protections: Short circuit Over Voltage Over temperature
Other features:

Built-in active PFC function
No load power consumption <0.5W
IP67 IP65 rated design for indoor or outdoor installations
Metal housing design
Various Dimming options
5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
200

Output Voltage
36V

Dimmable (Type)
DALI

DC Output Adjustment
None

Dimensions
244x 71x 37.5

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3,GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity Line-Easrt 6KV, Line-Line 4KV)

Input Voltage
100-305VAC 142-431VDC

Safety Standards
UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1; IP65 or IP67 approved

Output Voltage Options
Single

Working Temperature
-40~+90°C

PDF Datasheet
ELG-200-spec.pdf
