ELG-200-36 – Mean Well LED Driver ELG-200-36 199.8W 36V on Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant current mode output
Typical lifetime>50000 hours
Protections: Short circuit Over Voltage Over temperature
Other features:
Built-in active PFC function
No load power consumption <0.5W
IP67 IP65 rated design for indoor or outdoor installations
Metal housing design
Various Dimming options
5 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
200
Output Voltage
36V
Dimmable (Type)
No
DC Output Adjustment
None
Dimensions
244x 71x 37.5
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3,GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity Line-Easrt 6KV, Line-Line 4KV)
Input Voltage
100-305VAC 142-431VDC
Safety Standards
UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1; IP65 or IP67 approved
Output Voltage Options
Single
Working Temperature
-40~+90°C
PDF Datasheet
ELG-200-spec.pdf
