ELED-360-24DP2 – Ecopac ELED-360-D Series LED Driver 360W 24V (DALI2 & Push Dimming) Online now

Ecopac ELED-360-D series constant voltage LED driver. DALI and Push dimmable

Constant voltage PWM Output
DALI & Push dimming function
AC input: 100-265VAC
Built-in active PFC function
Efficiency up to 91.2%
Protections: Short circuit Over load Over temperature
Cooling by free air convection
IP66 design for indoor and outdoor installation
Suitable for intelligent LED lighting
More Information

Manufacturer

Ecopac Power

Output Wattage (W)

360

Output Voltage

Choose Option

Dimmable (Type)

DALI, Push Dimming

Dimensions

276 x 78 x 47mm

EMC Standards

Safety According to EN61000-4-2,3,4,5,6,11, EN61547, EN55015, EN61000-3-2, 3 (>60%load)

Input Voltage

100-265VAC

Safety Standards

EN61347-1, EN61347-2-13, IP66

Output Voltage Options

Single

Working Temperature

-40 ~ +60°C

PDF Datasheet

ELED-360-D.pdf
