ELED-200-12V – Ecopac Constant Voltage Dimmable ELED-200-12V 200W 12V For Cheap
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
0-10V Potentiometer 10V PWM dimmableConstant voltage designProtections: Short circuit Overload Over Voltage Over TemperatureOther features:Universal AC input Full rangeIP66 design for indoor or outdoor installationsBuilt-in PFC functionCooling by free air convection85% efficiency3 years warranty
More Information
Manufacturer
Ecopac Power
Output Wattage (W)
180
Output Voltage
12V
Dimmable (Type)
0-10V, Potentiometer, 10V PWM dimmable
Dimensions
256x 80 x 53 (LxWxH) Mm
EMC Standards
Compliance to EN55015, EN61000-3-2 (>50% load) Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, A light industry level
Input Voltage
100-265VAC
Safety Standards
EN61347-1-12 IP66
Output Voltage Options
Single
Working Temperature
-40~+60°C
PDF Datasheet
ELED-180-200V-Series.pdf
