ELED-100-V-S – Ecopac ELED-100-V Series Dimmable LED Driver 100W 12-24V Hot on Sale

Constant Voltage Design
0-10V Dimmable
Protections: Short circuit Over Voltage Over Temperature
Other features:

Dimming range from 0.1% to 100%
Range 100-265VAC
Built-in PFC function
IP66 design for indoor or outdoor installations
87% efficiency
3 years warranty
More Information

Manufacturer

Ecopac Power

Output Wattage (W)

100

Dimmable (Type)

0-10V

Dimensions

230x 70x 44

EMC Standards

Compliance to EN55015, EN61000-3-2 (>50% load) Compliance to EN61000-4-2,3,4,5,6,11 (Surge 4KV)

Input Voltage

100-265VAC

Safety Standards

EN61347-1, EN61347-2-13

Output Voltage Options

Single

Working Temperature

-40~+60°C

PDF Datasheet

ELED-100 200~10V Series.pdf
