ECP30-24VF-1 – Ecopac ECP30-24VF-1 Slimline Constant Voltage LED Driver 30W 24V Online now

The Ecopac Power ECP30-24VF-1 slimline constant voltage LED driver is ideal for concealment where space is restricted, such as hiding behind a strip. Short circuit, over temperature and over loading protection are all standard features.
Ecopac Power LED Drivers are supplied with a 3 year warranty.
Other features:

Slim line LED Driver
Universal AC input Full range 180-264VAC
Input Frequency 50 60Hz
24V Constant voltage output
3 years warranty
More Information

Manufacturer
Ecopac Power

Output Wattage (W)
30

Output Voltage
24V

Dimmable (Type)
No

DC Output Adjustment
N a

Dimensions
251x 30x 16mm

EMC Standards
EN55024 (IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5)

Input Voltage
200-240VAC

Safety Standards
EN55022 (EN61000-3-2, EN61000-3-3)

Working Temperature
0~+40°C

PDF Datasheet
ECP30-VF-1.pdf
