CLG-150-30B – Mean Well LED Driver CLG-150-30B 150W 30V For Cheap

Built-in active PFC function, PF>0.9 for 75% of load or higherBuilt-in constant current limiting circuit (C.V + C.C mode)Protections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 295 VAC) Full rangeIP67 ratedC.C. level can be adjusted through output cableCooling by free air convectionSuitable for LED lighting, street lighting and moving sign applicationsMeet 4KV surge immunity level (IEC 61000-4-5)3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
150

Output Voltage
30V

DC Output Adjustment
Constant current level adjustable through output cable

Dimensions
222 x 68 x 39

EMC Standards
EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547

Input Voltage
90~295VAC, 127~417VDC

Safety Standards
UL60950-1 , UL1012, UL8750, TUV EN60950-1, EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+70°C (refer to output derating curve)

PDF Datasheet
CLG-150-spec.pdf
