APV-16-15 – Mean Well LED Driver APV-16-15 15W 15V Hot on Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant Voltage
Fully isolated plastic case
Protections: Short circuit Overload Over voltage
Other features:
Universal AC input Full Range
Small and compact size
Isolation class II, no FG
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
15
Output Voltage
15V
Dimmable (Type)
No
DC Output Adjustment
N A
Dimensions
77 x 40 x 29
EMC Standards
EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
Input Voltage
90~264VAC; 127~370VDC
Safety Standards
Design refer to TUV EN60950-1, EN61347-2-13, UL8750
Output Voltage Options
Single
Working Temperature
-30°C~+70°C (Refer to Derating Curve )
PDF Datasheet
APV-16-5_20spec_1_.pdf
