APC-25-350 – Mean Well LED Driver APC-25-350 25W 350mA Online

$8.54

29 people are viewing this right now
10 products sold in last 15 hours
Selling fast! Over 7 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Constant CurrentFully isolated plastic caseProtections: Short circuit Overload Over voltageOther features: Universal AC input Full RangeSmall and compact sizeWithstand 300VAC surge input for 5 secondsIsolation class II, no FGCooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
25

Output Current
350mA

Dimmable (Type)
No

Output Voltage Range (V)
25~70

Dimensions
84x 57x 29.5

EMC Standards
EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A

Input Voltage
90~264VAC, 127VDC~370VDC

Safety Standards
Design refer to EN60950-1, UL8750

Output Voltage Options
Single

Working Temperature
-30°C~+70°C (Refer to Derating Curve )

PDF Datasheet
APC-25-spec.pdf
