APC-16E-350 – Mean Well LED Driver APC-16E-350 16.8W 350mA Online Sale

Constant CurrentFully isolated plastic caseProtections: Short circuit Over VoltageOther features:Small and compact sizeNo load power consumption <0.5WIP42 designClass II power unit, no FGCooling by free air convectionPass LPSSuitable for LED lighting and moving sign applications100% full load burn-in testLow cost, High reliability2 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
16

Output Current
350mA

Dimmable (Type)
No

Output Voltage Range (V)
12~48

DC Output Adjustment
12-48V

Dimensions
77 x 40 x 29

EMC Standards
EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A

Input Voltage
180~264VAC; 254~370VDC

Safety Standards
IP42 approved; design refer to EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+70°C

PDF Datasheet
APC-16E-spec.pdf
