Showing 1–16 of 17 results
1 x 36W T8 & TC-L DIM 1-10v – Helvar EL1x36sc Controllable (1-10 V) electronic ballast Ballasts catalogue Lifetime up to (h): 50000 Dimming range: 1 % – 100 % Input voltage: 220 V – 240 V Lamp type: T8 (36 W), TC-L (36 W), TC-F (36 W) Start options: Warm start Technical Length (mm) 360 Height (mm) 21 Width…
Controllable (1-10 V) electronic ballast Input voltage: 220 V – 240 V Lamp type: T5 (24 W), T5-eco (24 W), TC-L (24 W), TC-F (24 W) Lifetime up to (h): 50000 Dimming range: 1 % – 100 % Warm start Energy efficiency class: A1 Length (mm): 430 Width (mm): 30 Height (mm): 21 Fixing length…
Controllable (1-10 V) electronic ballast Input voltage: 220 V – 240 V Lamp type: T8 (58 W) Lifetime up to (h): 50000 Dimming range: 1 % – 100 % Warm start Energy efficiency class: A1 Length (mm): 430 Width (mm): 30 Height (mm): 21 Fixing length (mm): 420
EL2x36sc Controllable (1-10 V) electronic ballast Input voltage: 220 V – 240 V Lamp type: T8 (36 W), TC-L (36 W), TC-F (36 W) Lifetime up to (h): 50000 Dimming range: 1 % – 100 % Warm start Energy efficiency class: A1 Length (mm): 430 Width (mm): 30 Height (mm): 21 Fixing length (mm): 420
The Helvar EL SC 1x36HFC now a Helvar EL1x36sc is a dimmable high frequency ballast is to run 1 x 36w T8 fluoresent tube. They can be dimmed from 1-100%, extremeley low energy consumption, Flickerless light, Optimum cathode control and simultaneous lighting control by switch-control and analog control. Technical Length (mm) 360 Height (mm) 21…
Technical Specifications Control Gear Type High Frequency Accessory Type Ballast Wattage 28 W Manufacturer Helvar Dimming? Dimmable No. Of Lamps Twin (2x) Fixing Centers 420mm Height 28 mm Lamp 2x28w T5 Length 430 mm Type Control Gear Terminals 8 Width 30 mm Compatible Lamp Type T5 Control Gear Technology Fluorescent
EL1x39sc Controllable (1-10 V) electronic ballast Ballasts catalogue Lifetime up to (h): 50000 Dimming range: 1 % – 100 % Input voltage: 220 V – 240 V Lamp type: T5 (39 W), TC-L (40 W), T5c (40 W) Start options: Warm start Specifications Technical Length (mm) 360 Height (mm) 21 Width (mm) 30 Dimming 1-10 V Energy efficiency class A1…
EL4x14sc Controllable (1-10 V) electronic ballast Input voltage: 220 V – 240 V Lamp type: T5 (14 W), T5-eco (14 W) Lifetime up to (h): 50000 Dimming range: 3 % – 100 % Warm start Energy efficiency class: A1 Length (mm): 430 Width (mm): 30 Height (mm): 21 Fixing length (mm): 420
913700626566 HF-R 2 26-42 PL-T C EII 220-240V 50 60Hz Compact, high-frequency electronic dimming ballast, using the analog protocol (1-10 V) for PL-T, PL-C and PL-R lamps;The ballast is primarily designed for Indoor application. For outdoor application, the luminaire should be minimum ClassⅠand need to be sufficiently protected against water & dust. The installation should…
General Information Remarks UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG Application code EII Type version mk2 Lamp type TL-D Number of lamps 2 piece unit Number of products on MCB (16 A type B) (nom.) 12 Automatic restart Yes Operating and Electrical Input Voltage 220 to 240 V Input…
2 x28 54w Intelligent 1-10v Dimming Ballast – QTi 2X28 54 DIM – 4050300870717 echnical Data Electrical data Input voltage AC 198…264 V Nominal voltage 220…240 V Mains frequency 50…60 Hz Input voltage DC 154…276 V Maximum output power 2 x 49 W Efficiency in full-load 93 % Operating frequency 44…120 kHz Max. ECG no….
This item no longer available please consider the below item as a viable alternative Alternative 1x39w TL5 1-10v Analogue Dimming Ballast – HFR139TL5E11 – 91468230
2X 39w T5 Analogue Dimming Ballast – Philips – 913700633266 – HF-R 239 TL5 EII – 914774330
Osram QTi 1×21-35w Ballast Dimmable – Osram – QTI1x21 35DIM – 4050300870564 Will also run a 70W T8 1-10V Dimmable QTi 1X21 39 DIM Product benefits Same luminous flux with direct and alternating current Perfect lamp start for applications with motion sensors Dimming of amalgam lamps without flickering or reduced lifespan Very high efficiency thanks…
Osram QTi 1×35 49 80w Ballast Dimmable – Osram – QTI135DIM – 4050300870540 QUICKTRONIC INTELLIGENT DIM T5 Dimmable 1-10V. ECG for compact fluorescent lamps and T5 fluorescent lamps. Nominal voltage 220 – 240 VMains frequency 50 Hz 60 HzDC voltage 154…276 VOperating frequency 44…120 kHzStarting time 0.6 sLength 360 mmWidth 30 mmHeight 21 mmMounting hole spacing,…
Data sheet Item details Manufacturer: OSRAM Item No.: 25476 GTIN: 4050300870670 Voltage (V): 220-240 Life Time (h): 100000 Dimmable: yes
