ET-PARROT 70 220…240 I on Sale

Technical Data

Electrical data

Lamp wattage

20…70 W

Maximum output power

70 W

Line current

0.30 A

Nominal voltage

220…240 V

Power factor λ

0.95

Operating frequency

50 kHz

Nominal output voltage

11.9 12.0 V

Input voltage AC

198…264 V

Mains frequency

50…60 Hz

System wattage

74.00 W

Efficiency in full-load

94 %

Input voltage range

220…240 V

Max. ECG no. on circuit breaker 10 A (B)

37

Max. ECG no. on circuit breaker 16 A (B)

59

Galvanic isolation primary secondary

4.00 kV

Inrush current

0.45 A

Dimensions & weight

Length

128.0 mm

Width

38.0 mm

Height

31.0 mm

Mounting hole spacing, length

119.0 mm

Cable cross-section, input side

0.75 mm²

Cable cross-section, output side

0.75 mm²

Wire preparation length, input side

12 6.0 mm

Wire preparation length, output side

12 6.0 mm

Product weight

115.00 g

Temperatures & operating conditions

Ambient temperature range

0…+45 °C

Maximum temperature at tc test point

70 °C

Additional product data

Design version

Compact

Capabilities

Dimming method

Trailing- or leading-edge phase control for inductive load dimmers

Overload protection

Automatic reversible

Overheating protection

Automatic reversible

Short-circuit protection

Automatic reversible

Max. cable length to lamp LED module

2.0 m

Cable wire types, input side

H03VV-F 2×0.75 mm²

Cable wire types, output side

H03VV-F 2×0.75 mm²

Dimmable

Yes

Dimming range

0…100 %

No-load proof

Yes

Suitable for fixtures with prot. class

II

Intended for no-load operation

No

Certificates & standards

Approval marks – approval

VDE EAC

Standards

Acc. to EN 61347 Acc. to EN 55015 Acc. to EN 61000-3-2 Acc. to EN 61547

Type of protection

IP20
